ICET ® thermal insulation material
1、 Product Overview:
The thermal insulation products are specially developed for the rail transit and passenger bus industry, which are NBR synthetic rubber closed cell and elastic insulation material. Its stable and reliable insulation performance contributes to a dual guarantee of comfort and energy conservation for rail transit and passenger buses.
Application: Composite materials for bus body side panels/roof/engine compartment.
2、 Parameters
|
Technical data |
|
| Flame retardant properties |
▶ European Bus ECE R118 ▶ JT/T 1095-2016 ▶ GB 38262-2019 |
| Thermal conductivity | ≤0.032W/(m.K）-20℃，≤0.034W/(m.K）0℃，≤0.039W/(m.K）40℃ |
|
Odor properties |
VDA270 test at 80 ℃, odor meets ≤ 3.5 |
| Oxygen index |
>39% （GB/T 2406）
|
|
Specification and size |
||
| product | size/thickness（mm） | package |
| ICET insulation foam | 1500 * 4000 * 15 | sheet |
|
ICET insulation foam |
1500 * 4000 * 25 |
sheet |
|
ICET insulation foam |
1500 * 4000 * 40 |
sheet |
3、 Product Description
| advantage |
•The product is a synthetic rubber closed cell and elastic insulation material •Elastic material is featured in good sound insulation and vibration reduction performance •The product is fiber and dust free, low VOC, and environmentally friendly •Strong resistance to ultraviolet radiation; when used outdoors, no need to lay an outer protective layer, the product performance can remain stable for a long time under sunlight and accidental contact with oil stains •The closed cell structure does not require a gas barrier, waterproof and moisture-proof, with a long service life •Highly soft, PVC free and CFC free, fiber free, dust-free, environmentally friendly • Meet the technical requirements of German standard DIN 1988 parts 2 and 7 • available with high-quality adhesive technology , easy to install without special tools • thermal conductivity: ≤ 0.038W/(m.K), 0 ℃, ≤ 0.042W/(m.K), 40 ℃ |
|||
